SRS
Free-Standing & Built-In RTL Subwoofer
The SRS addresses the need for high output subwoofers with minimal size vent openings, offering improved integration, with a focus on Large Micro LED Display installations.
The SRS’s highly efficient dual 10-inch woofers, built in an optimized transmission line, results in articulated bass with superior dynamics and accurate timbre, making it the perfect solution for the ultimate Music and Movie reproduction within large residential and theater spaces.
The Regenerative Transmission Line®
Regenerative Transmission Line® designs yielded the unique combination of high sensitivity, high output, and low distortion with the uniform and extended response we required. The result is extraordinary power and punch combined with a remarkable level of speed, tunefulness, and realism.
Key Features
Free-Standing
Behind Baffle
Behind Screen-Wall
Ported into Room
Regenerative Transmission Line® Design
Highly Detailed & Dynamically Accurate
(2) Custom Designed High-Output Long Throw 10” Woofers
Optional floor/ceiling extension port kit available for venting into space from an adjacent room, attic, riser, ceiling, and/or floor.
Four Multi-port design allows for flexibility in how the SRS output is ported into the room.
Flat Frequency Response Across a 20Hz-80Hz±3dB Operating Range
(2) 10″ High Operating Woofers
DSP Required
(1) Channel of Power Amplification per Subwoofer Required
Specification
Frequency Response | 18Hz –125 Hz ± 3dB / -10dB at 15Hz |
Impedance | 4 ohms |
Sensitivity | 96 dB / 2.83V / 1m |
Power Handling, Peak | 1600 Watts |
Max SPL | 125dB / 1m |
Product Weight | 147 lbs (66.7kg) |
Shipping Weight | Coming Soon |
Dimensions – HxWxD | 29.5″ x 43.9″ x 11.9″ (74.93cm x 111.51cm x 30.23cm) |
